The GSM-R mobile phone focX®2 is part of the new generation of our focX product range®. It is a GSM-R terminal device for professional mobile communication applications and is equipped with a radio module that ensures communication in the railway radio network. Interfaces for public networks (2G, 3G, 4G), WLAN and Bluetooth are available and can be used.
The focX®2 fulfils the requirements of the European EIRENE standards FRS 8.1 and SRS 16.1 and is the world's first available handheld radio with integrated filters to meet the requirements of TS 102-933, v2.1.1. Together with the transmission power of 2W in GSM-R mode and the intuitive user guidance, the device supports safe and smooth communication.
147.5 mm
72.2 mm
35 mm
approx. 342 g
ER-GSM / GSM 900 / E-GSM 900 / DCS 18000
B1 / B2 / B5 / B8
B1 / B3 / B5 / B7 / B8 / B20 / B28 / B34 / B38 / B39 / B40 / B41 / B42
2 W ± 2 dB (GSM/GSM-R), 1 W ± 2 dB (DCS 1800), 250 mW (3G/WCDM), 200mW (4G/LTE)
-25°C to +55°C
-40°C to +70°C
IP68 (dustproof, permanently waterproof up to a depth of 1.50 m for a maximum of 30 minutes)
against the effects of brake fluid, engine and transmission oil
3.55″ colour display, 320 x 480 pixels (HVGA)
1 microphone, 2 loudspeakers
5,500 mAh lithium-ion battery (replaceable)
Android
3 GB main memory (RAM), 24 GB phone memory (ROM)
4-core CPU
Mediatek Helio A22 MT6761
Distance sensor, accelerometer, light sensor, magnetic sensor
Configuration and software update via external interface
Automatic band switching
GSM ASCI application (Phase 2+)
GSM-R application with manoeuvring mode*
GPS / GLONASS / GALILEO / Beidou
Can be operated with gloves
13 MP camera
PTT button left
WiFi standards a/b/g/n/ac
Slot for micro SD card
HF Monitor
Speed dialling register
SMS
Automatic redialling
Dual SIM
Tilt sensor optional
Configuration cloning
LAS button left
Specific emergency call button
Touch display
* available in future software version
